  PRODUCT DETAILS > SPEED CONTROLLERS > > ZTW 40A ESC BURST 80A/ 10SEC
ZTW 40A ESC Burst 80A/ 10sec (#ZTW 40A ESC)

2-4S Lipo BEC 3A 5.5V peak 5A




Price: R520

Weight: 36 grams



Product Details:

Super smooth, accurate and programmable throttle linearity and throttle response.
Over temperature protection ,low voltage cut off protection ,signal loss protection and so on.
Strong BEC output 3A/5.5V continuous and peak to 5A.
Supporting high RPM motors and programmable by programming card and transmitter .
High efficiency with low resistance and low heat MOSFET and CPU.

Key Features :
Aluminum heat sink to lower ESC heat.
Adjustable softstart according to different RPM and Pole Motor.
Supporting High RPM and Pole Motor.
Functions programmable : Brake,cut off voltage,softstart,motor direction etc.

Description :
Size :52mm x 27mm x 11mm (LxWxH).
Battery : 2-4S Lipo / 5-12NC.
Voltage : 7.6V-15.8V.
Current :40A ,peak 80A for 10 seconds.
BEC output : 3A/5.5V, peak 5A
Weight :36g.
Motor Type : Brushless (no brushed)
RPM supports: 200,000 for 2P, 82,000 for 6P, 42,000 for 12 P.

Package includes :
ESC x 1
User Manual x 1

Note
Please do make the throttle calibration for the first time using or changed the TX.
