  PRODUCT DETAILS > > > SAVOX WING SERVO SG0211 6V, 8KG 0.13SEC
Savox Wing Servo SG0211 6V, 8KG 0.13sec (#SAVOX SG0211)

Digital Slim Wing Servo




Price: R975

Weight: 30 grams



Product Details:

Savox SG-0211MG - High Torque Metal Case Digital Glider Servo, .13 / 111.1@ 6V

The SG-0211MG is specifically designed for glider and sailplane applications. With its unique case design, it is meant to be mounted in the slim specifications of wings.
Features:

Metal Gear train for extended life and durability.
Special design for glider applications.
Special design for glider applications.
All aluminium case for secure mounting.

Specifications:

Torque @4.8v - 6.0kg / 83.3oz-in
Torque @6v - 8.0kg / 111.1oz-in
Speed @4.8v - 0.16 sec/60 deg
Speed @6v - 0.13 sec/60 deg
Dimensions L x W x H (mm): 30.0 x 10.0 x 36.0
Weight: 29g

Technical Details:

Operating Temperature: -10 to 50 deg Celcius
Running Current (no load): 120mA @4.8V, 180mA @6.0V
Stall Current (at locked): 1500mA @4.8 V, 1900mA @6.0V
Idle Current: 5mA @4.8V, 5mA @6.0V
Wire Length: 250 plus/minus 5mm
Output Gear Spline: 21 Tooth
Bearings: 2BB
Operating Travel: 100 deg (1000 to 2000 micro second)
Neutral Position: 1500 micro second
Pulse Width Range: 800 to 2200 micro second
Maximum Travel: Appx 165 (800 to 2200 micro second)
Refresh Rate: 240 Hz
Motor Type: Brushed
