| PRODUCT DETAILS > > > CORONA CS239 MG SLIM WING SERVO |
Corona CS239 MG Slim Wing Servo (#SLIM-COR239MG)
|
Analog Servo 4.6kg/ 22g / 0.14sec
|
Price: R0
Weight: 22 grams
|
|
|
|
Product Details:
Corona CS-239MG Slim-Wing Analog Servo 4.6kg/22g / 0.14sec
Spec.
Model: CS-239MG
Operating Voltage: 4.8V / 6.0V
Operating Current: 300mA / 400mA
Operating Speed: 0.15sec.60/ 0.14sec.60
Stall Torque: 4kg.cm /4.6kg.cm
Size: 30x10x34mm
Weight: 22g
Dead Band: 5uSec
Operating Travel: 40/one side pulse traveling 400us
Potentiometer: 3 slider/Indirect Drive
Gear: Metal
Connector wire: 215mm
Operating Temperature Range: -20c+60c
|
 Click here to download the technical specifications/manual
|
